Key Features & Benefits
✅ Ultra-Lightweight & High Strength
Only 1/4 the density of steel, significantly reducing structural weight while maintaining equivalent strength to avoid additional load burdens
Tensile strength up to 5800MPa, far exceeding ordinary steel, effectively improving structural load-bearing capacity and damage resistance
✅ Excellent Flexibility & Versatility
Highly flexible fabric that conforms tightly to complex-shaped and curved components for full-coverage reinforcement
Unidirectional fiber design directs loads precisely to the force direction, maximizing reinforcement efficiency
✅ Fast & Efficient Installation
Easy to cut and apply by hand without heavy machinery or complex tooling, shortening construction cycles and improving efficiency
Compatible with resin impregnation processes, forming a monolithic bond with components without occupying additional structural space
✅ Durable & Corrosion-Resistant
Outstanding resistance to acids, alkalis, salt spray, and corrosion, performing reliably in humid and chemically aggressive environments
Excellent anti-aging and anti-fatigue properties with minimal performance degradation over long-term service, ensuring structural stability.
Product Specification
|
Fiber Type |
Tensile Strength |
Modulus of Elasticity |
Elongation at Break |
Weight (g/m²) |
|
T300-12000 |
≥3500 MPa |
≥230 GPa |
≥1.5% |
198 |
|
T300-12000 |
≥3500 MPa |
≥230 GPa |
≥1.5% |
396 |
|
T700S-12000 |
≥4900 MPa |
≥240 GPa |
≥2.1% |
400 |
|
T700S-12000 |
≥4900 MPa |
≥240 GPa |
≥2.1% |
800 |
|
T800S-12000 |
≥5800 MPa |
≥294 GPa |
≥2.0% |
515 |
|
T800S-12000 |
≥5800 MPa |
≥294 GPa |
≥2.0% |
1030 |
|
Custom weights and widths available upon request, with application guidance for compatible impregnation resins |
Process Flow Diagram

Product Applications



Product Workshop






FAQ
