Product Specification

Key Features & Advantages

✅ Exceptional Mechanical Performance

High specific strength and modulus: Delivers superior strength-to-weight ratio compared to traditional materials like steel and aluminum

Excellent fatigue resistance: Maintains structural integrity under repeated load cycles

Outstanding dimensional stability: Low thermal expansion coefficient ensures consistent performance across temperature variations

✅ Multi-Functional Properties

Electrical conductivity: Provides inherent EMI shielding capabilities for electronic applications

Excellent X-ray permeability: Suitable for medical equipment and non-destructive testing applications

Thermal oxidation resistance: Withstands high-temperature environments without significant performance degradation

Corrosion resistance: Resists chemical attacks from acids, alkalis, and moisture for long-term durability

✅ Versatile Weave Options

Plain Weave: Balanced, uniform structure with excellent stability and dimensional control, ideal for general reinforcement

Twill Weave: Better drapeability and conformability, perfect for complex-shaped parts and curved surfaces

Product Type	Fiber Grade	Weave Style	Weight (g/m²)	Thickness (mm)	Available Width (m)
ZC-1K Plain/Twill	1K Carbon Fiber	Plain / Twill	120	0.16	0-2.3
ZC-3K Plain/Twill	3K Carbon Fiber	Plain / Twill	160	0.18	0-2.3
ZC-3K Plain/Twill	3K Carbon Fiber	Plain / Twill	200	0.22	0-2.3
ZC-3K Plain/Twill	3K Carbon Fiber	Plain / Twill	280	0.30	0-2.3
ZC-12K Plain/Twill	12K Carbon Fiber	Plain / Twill	400	0.45	0-2.3
ZC-12K Plain/Twill	12K Carbon Fiber	Plain / Twill	450	0.50	0-2.3

Custom specifications (weights, widths, weaves) available upon request

Process Flow Diagram

Product Applications

Common Applications

Our carbon fiber woven fabric is widely used in industries requiring high-performance lightweight materials:

Aerospace & Aviation: Aircraft components, interior parts, structural reinforcements

Automotive: Racing parts, body panels, interior trims, lightweight structural components

Sports Equipment: Bicycle frames, fishing rods, golf clubs, tennis rackets

Industrial Applications: Robotics, pressure vessels, medical equipment, wind turbine blades

Marine: Boat hulls, yacht components, marine structural parts

Why Choose Our Carbon Fiber Woven Fabric?

Consistent Quality: Strict quality control throughout the production process ensures uniform fiber distribution and stable performance

Customization Options: Multiple specifications and weaves to meet diverse application requirements

Cost-Effective: Competitive pricing without compromising on material quality

Reliable Supply: Stable production capacity to support both small-batch and large-scale orders

For more details or custom orders, please contact our sales team.

Product Workshop

FAQ

Q: What is the service life of your carbon fiber cloth?

A: Under normal use and regular maintenance, the service life is 15-20 years, which is much longer than that of traditional metal materials and glass fiber cloth.

Q: Can you provide samples for testing?

A: Yes, we can provide free small samples for performance testing, and the sample delivery time is 3-5 working days.

Q: What is the difference between unidirectional and bidirectional carbon fiber cloth?

A: Unidirectional carbon fiber cloth has super tensile performance in a single direction, which is the first choice for engineering reinforcement; bidirectional carbon fiber cloth has tensile performance in both horizontal and vertical directions, but the bearing capacity in a single direction is only 50% of that of unidirectional cloth, which is only suitable for local anti-cracking repair.
